Hydraulic Hose Swivel Assembly 3/8" with Female JIC X Female JIC, 5000PSI W.P., -40°F to 212°F, Wear Resistant Synthetic Rubber Hydraulic Hoses, 144 Inch Long, SAE 100 R2
Product details
| Management number | 222653608 | Release Date | 2026/05/04 | List Price | US$25.60 | Model Number | 222653608 | ||
|---|---|---|---|---|---|---|---|---|---|
| Category | |||||||||
- 2-Ends: 3/8 inch Female X 3/8 Female JIC 37°Hydraulic Hose Fittings.Working Pressure: 5000 PSI.
- Easy to Use: Super easy to install – Each hose comes with the Female JIC swivel nut already crimped. The nut part of the joint can rotate freely, while the body of the joint (and the 37 degree conical surface part) remains stationary. As there is no need to twist the entire hose or connector body to tighten the nut, simplifying installation in tight spaces. The precision 37° flare seal ensures leak-proof performance even under high vibration, supporting repeated use without loss of integrity.
- HIGH QUALITY MATERIALS AND STRUCTURE:The inner and outer layers are made of wear-resistant synthetic rubber, and the middle layer is reinforced with two high-strength steel wire braided layers to ensure that the hose is resistant to deformation and impact in extreme environments. The outer layer has excellent wear resistance, aging resistance and ozone resistance (passing the 50pphm ozone test), extending the service life of outdoor, mining and other harsh environments.
- HIGH-STRENGTH AND PRESSURE RESISTANT DESIGN: Built with dual-layer steel wire braiding, the working Pressure is 5000PSI, making it ideal for high-pressure applications like injection molding machines and cranes. It remains reliable across a wide temperature range of -40°F to 212°F (-40°C to 100°C), with inner and outer layers made of synthetic rubber that stay flexible and sealed in extreme cold or heat, preventing hardening or cracking.
- WIDELY USED APPLICATIONS: 3/8" hydraulic hose assembly with jic fitting can be used in the actuators of construction and agricultural machinery, as well as in industrial systems. They are commonly applied in the working oil circuits of small and medium-sized excavators/loaders, the hydraulic suspension and steering systems of tractors, and industrial equipment such as the mold clamping and opening circuits of injection molding machines, die-casting machines, and forklifts.
| Color | Black |
|---|---|
| Brand Name | Redrock Performance |
| Unit Count | 1.0 Count |
| Manufacturer | Redrock Performance |
| Material Type | 2 High-Tensile Steel Wire Braids, Synthetic Rubber |
| Maximum Pressure | 4000 Pound per Square Inch |
| Outside Diameter | 0.38 Inches |
| Included Components | 1/2" Female X 1/2" Female JIC 37° Swivel Nut |
| Item Dimensions L x W | 144"L x 0.38"W |
